Seated Remote Control Grinder GX-888
frequency transformer 25 P Hapemont
any power generating or power driven machine 18.5 KW
source Three-phase AC 380 V*35 A
Self rotation speed 0-1800 rpm(revolutions per minute adjustable)
Speed of rotation 0-200 rpm (revolutions er minute adjustable)
speed of travel 0-20 m/min(revolutions per minute adjustable)
Walking motor 2×1.0 kW(dual drive)
Working width 870 mm
Number of grinding pieces Four plates 24 pieces(315 mm*4)
control method Manual self-drive/remote control total weight 650 Kg
Free shipping on orders over $50!
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
1.Using high precision gearbox body,
long life,high precision;
2.Integrated frame is flat and durable,
three-level weight design,easy to operate;
3.Equipped with 15 Kw high power motor to ensure strong power,
the electrical control components are imported Schneider Electric;
4.Walking adopts single-drive design,
walking speed can bead justed,save time and effort.
| Weight | 1510 lbs |
|---|---|
| Dimensions | 150 × 95 × 135 in |
| frequency transformer | 25P Hapemont |
| any power generatingor power driven machine | any power generatingor power driven machine |
| source | Three-phase AC 380V*35A |
| Walking motor | 2×1.0kW(dual drive) |
| Working width | 870 mm |
| Number of grinding pieces | Four plates 24 pieces(315 mm*4) |
